Double Girder Semi Gantry Crane

Gantry Crane

Rated Loading : 25 Ton, 30 Ton, 20 Ton

Travelling speed : 20-30(m/min)

Lifting height : 6,9,12,18,24,30 (m)

Orbital width : 37-70 (mm)

PDF DOWNLOAD

Send Inquiry

Email Contact

Product Details

The double girder semi-gantry crane with hook is mainly composed of gantry, crane crab, trolley travelling mechanism and electric control system. The gantry, of a box-shape structure, has a leg at its one side and runs along the ground rails, and has no leg at the other side and runs along the rails on the factory workshop. The closed cab is employed for operation, where there are adjustable seat, insulating mat on the floor, toughened glass for the window, fire extinguisher, electric fan and auxiliary equipment such as air conditioner, acoustic alarm and inter-phone which can be furnished as required by users.

Girder-Semi-Gantry-Crane

Product Features

1. Compact structure, good rigidity.

2. Favorable performance,

3. Smooth starting and stopping,

4. Safe and reliable traveling, strong ability of lateral load proof.

5. Low noise, no pollution.

6. Flexible installation and operation, convenient maintenance,

7. Electricity saves

8. Excellent exchange ability for parts and components.

9. Less investment

Product parameters

Crane operate mechanism Travelling speed(m/min) 20 30
Reduction ratio 58.78 39.38
58.95 39.42
motor type 21-4
Power (kw 2x0.8
Revolving speed(r/min) 1380
Lifting mechanism(electric hoist)and travelling mechanism Model MGB
Lifting speed(m/min) 8(7) 8/0.8(7/0.7)
Lifting height(m) 6, 9, 12, 18, 24, 30
Travelling speed(m/min) 20, 30
Motor Conical squirrel-cage
Work duty A3-A5
Power source 3 phase 50Hz 380V
Wheel diameter ¢270mm
Orbital width 37-70mm

Leave Message To Us

FEW TIPS

  1.Load capacity: ton?

  2.Span of the crane: m?

  3.Max. lifting height of the crane: m?

  4.What materials will be handled: ?

  5.How many hours will the crane work per day: ?

  6.Your project introduction: project working site, project budget, etc.
